Frame
Alpha Gold Aluminium, tapered head tube, internal derailleur & dropper post routing, ISCG 05, threaded BB, Boost148
-
Fork
Size: XS, RockShox Recon Silver RL, SoloAir spring, Motion Control damper, lockout, tapered steerer, 37 mm offset, Boost110, Maxle Stealth, 140 mm travel
Size: S/M/ML/L/XL, RockShox Recon Silver RL, SoloAir spring, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, Maxle Stealth, 140 mm travel
-
Max compatible fork travel
150mm
-
Hub front
Shimano MT400, CenterLock, Boost110, 15 mm thru-axle
-
Hub rear
Shimano MT510, CenterLock, Boost148, 12 mm thru-axle
-
Skewer rear
Bontrager Switch thru-axle, removable lever
-
Rim
Bontrager Line Comp 30, Tubeless Ready, 28-hole, Presta valve
-
Tyre
Size: XS, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.60"
Size: S/M/ML/L/XL, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 29x2.60"
-
Tyre part
Size: XS/S/M/ML/L/XL, Bontrager TLR sealant, 180 ml/6 oz
Size: XS/S/M/ML/L/XL, Bontrager TLR valve, 50 mm
-
Rim strip
Bontrager TLR
-
Max tyre size
Frame: 29x2.60" (XS - 27.5x2.60") Fork: see manufacturer
-
Shifter
Shimano Deore M6100, 12-speed
-
Rear derailleur
Shimano Deore M6100, long cage
-
Crank
Size: XS/S/M/ML/L, Shimano MT511, 30T steel ring, Boost, 170 mm length
Size: XL, Shimano MT511, 30T steel ring, Boost, 175 mm length
-
Bottom bracket
Shimano SM-BB52, 73 mm, threaded external bearing
-
Cassette
Shimano Deore M6100, 10-51, 12-speed
-
Chain
Shimano Deore M6100, 12-speed
-
Pedal
VP-536 nylon platform
-
Max. chainring size
52mm chainline: 32T, 55mm chainline: 34T
-
Saddle
Bontrager Arvada, steel rails, 138 mm width
-
Seatpost
Size: XS/S, TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
Size: M, TranzX JD-YSP18, 130mm travel, internal routing, 31.6 mm, 425 mm length
Size: ML/L/XL, TranzX JD-YSP18, 150 mm travel, internal routing, 31.6 mm, 445 mm length
-
Handlebar
Size: XS/S, Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Size: M/ML/L/XL, Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 780mm width
-
Stem
Size: XS/S, Bontrager alloy, 31.8 mm, Blendr compatible, 7 degree, 35 mm length
Size: M/ML/L/XL, Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length
-
Head set
FSA IS-2, 1-1/8" top, 1.5" bottom
-
Brake
Shimano MT200 hydraulic disc
-
Brake rotor
Shimano RT10, CenterLock, 180 mm
-
Weight
M - 30.84 lbs / 13.99 kg (with TLR sealant, no tubes)
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
