An evolution that speaks for itself. The new MITH eliminates the barriers between regular and electric bikes regarding look and riding feel while offering the best range and power on the market.
170/160mm of travel, Mullet setup, and 800Wh battery.
Designed and engineered in Barcelona.
WORLDS LEANEST
e-MTB FRAME EQUIPPED WITH AN 800Wh BATTERY
The new MITH looks and rides like nothing else you have previously experienced.
DJI AVINOX - THE MOST POWERFUL DRIVE SYSTEM AVAILABLE
105Nm in normal mode and 120Nm in Boost. Drive unit 2,52kg and 800Wh battery 3,74kg. Battery charged in 2:25h with fast charger. 2 inch OLED tactile display. Ambient light sensor. GPS, IMU, barometer, compass. Torque/cadence/wheel speed sensor. 4G connection with real-time bike location. Security and alarm system. Seamless integration with DJI products.

TWILL CARBON WEAVE FINISH
The unique UNNO look is back on our Factory & Pro builds. The twill fabric finish is not only cosmetic but adds extra impact resistance. Additionally, our MITH frames are tested up to 2x the ISO norm, making us very confident to offer a lifetime warranty on any frame.
EXTRA SEAT POST INSERTION
We've shortened the seat tube and increased the insertion by 60mm while keeping our disruptive and unique frame design.
Now, the MITH comes with 150mm dropper posts in S1, 180mm in S2, and 210mm in S3.

ACCESSIBLE SHOCK AND COIL COMPATIBLE
The shock is now easily accessible for making setting adjustments and hassle-free maintenance, and the frame is compatible with coil shocks, too.

DUST GUARDS PROTECTION
All bearings are shield from mud, dirt, and water, enhancing their durability.

NO HEADSET CABLE ROUTING
We’ve ditched the trend of routing cables through the headset, gaining durability and ease of service. Additionally, the routing is now fully guided for a noiseless riding experience.

KINEMATICS
UNNO VIRTUAL PIVOT SUSPENSION REFINED
The suspension kinematics use an initial 30% of the curve with a higher progressive ratio for maximum small bump sensitivity, while the other 70% is less progressive to give enough platform to push the bike in corners and provide good bottom-out resistance.

recommended SAG setup
We propose 2 different SAG settings: 30% for a standard setup or 35% for an aggressive setup, especially on steeper trails. When using 35%, the bike is 0.5º slacker.
EXCEPTIONAL GROUND CLEARANCE
The MITH comes with 155mm stock cranks to provide exceptional ground clearance and a better-centered riding position. The frame has room for up to 2.6” tires.

AGGRESSIVE GEOMETRY WITH 63.5º HEAD ANGLE

REAL AUTONOMY.
Going for an endless adventure in the woods? Or racing against the sunset? You decide how you spend the 800Wh battery.
Frame and motor
Frame
MITH
Carbon fibre monocoque with 160mm of rear travel. Virtual pivot suspension system. Integrated display, battery, chain guide and seat tube clamp. Motor protector. EnduroMAX Bearings. Internal cable routing. Boost thru axle 12x148. Post Mount brake system. Max tire width: 2.6”. Recommended SAG: 30-35%.
Motor
DJI Avinox
2,52 Kg drive unit with 70Nm (Eco), 105Nm (Auto, Trail, Turbo) and 120Nm (Boost). Offers 250W (rated), 850W (peak) and 1000W (max.) of power.
Display
DJI Avinox 2-inch OLED
2-inch OLED smart multi-function touchscreen with 800 nits and 326 ppi.
Controller
DJI dual Wireless Controllers
Wireless Controllers with Bluetooth Connectivity
Battery
DJI Avinox 800Wh
Integrated 3.74kg battery, delivered with a fast charger, 0 to 100% in 2h 25min.
Heatset
CANE CREEK 40
TPR-IS41/28.6/H9 | IS52/40
Suspension
Fork
FOX PODIUM FACTORY
170mm travel. Kashima coating. Grip X2 damper. Adjustments: HSC, LSC, HSR, LSR. 44mm offset.
Shock
Fox Float X2 Factory
230x65mm. Kashima coating. 2-pos lever. VVC Rebound. Adjustments: HSC, LSC, HSR, LSR.
Transmission
Derailleur
SRAM XX EAGLE AXS T-TYPE
12 speed. AXS Wireless. T-type.
Controller
SRAM AXS
Pod rocker right discret clamp D1
Cassette
SRAM XX
T-Type. 12 speed. XS-1297. (10-52).
Crankset
E13 Helix Core e*spec
Wheelset
Wheels
NEWMEN Phase 30 Carbon
Mullet 29" Front and 27.5" Rear.
Front Tyre
SCHWALBE Magic Mary
Ultra Soft, Gravity Pro, TLR, 29” x 2.5”
Rear tyre
SCHWALBE Magic Mary
Soft Evo, Gravity Pro, TLR, 27.5” x 2.5”
Brakeset
Brakes
Formula Cura 4
4x18mm pistons on Caliper. SRAM Mixmaster. Sintered Pads. Axial Master Cylinder. Forged Aluminium. 850mm front hose and 2000mm rear hose.
Rotors
Formula
203mm front rotor, 200mm rear rotor with integrated speed sensor slots.
Cockpit and seat
Cockpit
OneUP
ONEUP V2 Carbon handlebar, 35mm diameter, 800mm length, 35mm rise & ONEUP 42mm stem
Dropper
ROCKSHOX Reverb AXS
Saddle
FIZIK Terra Aidon X1
