Marlin 7 Gen 3
Trek

Marlin 7 Gen 3

£1,000.00 Save £0.00
/
Tax included.
Only 1 items in stock!
Product Details

The Marlin 7 is your best friend on the trail and wherever else you roll thanks to its confidence-boosting trail geometry. It finds the perfect balance between price and performance with a RockShox suspension fork that makes quick work of rocks and bumps in your path, and loads of gears from the SRAM NX Eagle 12-speed drivetrain.



*Please note – spec applies to all sizes unless listed separately

Frameset
Specifications
*Frame Size: XS
Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
Size: ML , M , L , S , XL , XXL
Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
*Fork Size: XS , S
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
Size: ML , M , L , XL , XXL
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
Wheels
Specifications
*Front Hub Size: ML , M , XS , L , S , XL , XXL
Formula DC-20 LW, alloy, 6-bolt, 5x100 mm QR
*Rear Hub Size: ML , M , XS , L , S , XL , XXL
Formula DC-22LW, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
*Rear Skewer Size: ML , M , XS , L , S , XL , XXL173x5 mm QR
*Rim Size: ML , M , XS , L , S , XL , XXLBontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
Size: ML , M , L , XL , XXLBontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
*Tire Size: XS , S
Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5x2.40''
Size: ML , M , L , XL , XXL
Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.40''
*Rim Strip Size: ML , M , XS , L , S , XL , XXLBontrager TLR
Drivetrain
Specifications
*Shifter Size: ML , M , XS , L , S , XL , XXL
SRAM SX Eagle, 12-speed
*Rear Derailleur Size: ML , M , XS , L , S , XL , XXL
SRAM NX Eagle, 12-speed
*Crank Size: M , XS , S
SRAM SX Eagle, 30T steel ring, 49 mm chainline, 170 mm length
Size: ML , L , XL , XXL
SRAM SX Eagle, 30T steel ring, 49 mm chainline, 175 mm length
*Bottom Bracket Size: ML , M , XS , L , S , XL , XXL
Truvativ Powerspline, 73 mm, threaded cartridge, 118 mm spindle
*Cassette Size: ML , M , XS , L , S , XL , XXL
SRAM PG-1210 Eagle, 11-50, 12-speed
*Chain Size: ML , M , XS , L , S , XL , XXL
SRAM SX Eagle, 12-speed
*Pedal Size: ML , M , XS , L , S , XL , XXLVP-536 nylon platform
Components
Specifications
*Saddle Size: ML , M , XS , L , S , XL , XXLBontrager Verse Short, stainless steel rails
*Seatpost Size: XS , S
TranzX JD-YSI34, 100 mm travel, internal routing, 34.9 mm, 350 mm length
Size: M
TranzX JD-YSI34, 125 mm travel, internal routing, 34.9 mm, 405 mm length
Size: ML , L
TranzX JD-YSI34, 150 mm travel, internal routing, 34.9 mm, 456 mm length
Size: XL , XXL
TranzX JD-YSI34, 170 mm travel, internal routing, 34.9 mm, 500 mm length
*Handlebar Size: XS
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
Size: S
Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
Size: ML , M , L , XL , XXL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
*Grips Size: ML , M , XS , L , S , XL , XXLTrek Line Comp, nylon lock-on
*Stem Size: XS , S
Bontrager Comp, 31.8 mm, 7-degree, 35 mm length
Size: ML , M , LBontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Size: XLBontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length
Size: XXLBontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
*Headset Size: ML , M , XS , L , S , XL , XXL
Semi-integrated, 1-1/8"
*Brake Size: ML , M , L , XL , XXL
Shimano MT200 hydraulic disc
*Brake Rotor Size: ML , M , XS , L , S , XL , XXL
Shimano RT26, 6-bolt, 160 mm
Size: ML , M , L , XL , XXL
Shimano RT26, 6-bolt, 180 mm
*Brake Set Size: ML , M , XS , L , S , XL , XXL
Shimano MT200 hydraulic disc
Weight
Specifications
Weight M - 14.15 kg / 31.2 lbs
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
